CPU: 7th/8th/9th Gen CPU + Q170
SO-DIMM DDR4 up to 64 GB
8xUSB+6x COM+3xLAN
M.2, PICe/PCI 4*Slots
Key Features：
1. CPU: Intel 6th/7th/8th/9th Gen CPU + Q170
2. Memory: Dual channel SO-DIMM DDR4 up to 64 GB
3. Display via: 1x HDMI+ 1x VGA + 1x DP
4. I/O Interface: 8x USB3.2, 1x USB3.2*Dongle Onboard, 4x USB2.0(2*header), 6x COM, 3xLAN,
5. Expansion: M.2, PICe/PCI 4 Slots
6. Ethernet: 10/100/1000 Mbps
7. Storage: 2x 2.5' HDD + M.2 SSD
8. Expansion: M.2
9. Power: 16-36V DC-in
Specification FI0M-QA40-E1/E2/E3/E4 | ||
| CPU | CPU/Socket | lntel 6th/7th/8th/9th Gen Processors ( ≤ 45W） |
| Memory | Technology | DDR4 SODIMM x2 up to 64GB |
| Max. Capacity | 64GB | |
| Display | GPU | Intel HD Graphics based on CPU 1xHDMI + 1xVGA+ 1xDP |
| Storage | SATA | 2x SATA 2.5 inches HD 1x M.2 for 2280 SSD SATA |
| Expansion slot | 1x M.2 for WiFi 1x M.2 for 4G/5G | |
| Expansion slot | Optional | E1 1x Expansion Slot PCI/PCIe E2 2xExpansion Slot PCI/PCIe E4 4xExpansion Slot PCI/PCIe 1*PCIe8X+2*PCIe4X+1*PCIe2X or 1*PCIe16X+1*PCIe2X+2*PCI |
| Ethernet | Controller | 3x Intel® i211/i210 |
| Connector | 3* RJ45 LAN port | |
| Audio | 1xLine out, 1xMic in | |
| Watchdog Timer | Yes | |
| IO | USB3.2/2.0 | 2x USB2.0+8x USB3.2 + (1x USB3.2 Dongle OnBoard )+2xUSB2.0Header |
| LAN | 3x RJ45 Port, Ethernet LAN | |
| COM | 6xCOM | |
| Display | 1xHDMI + 1xVGA+ 1xDP | |
| GPIO | 16 bit GPIO | |
| Audio | 1 x Line out, 1xMic in | |
| Power | Power Type | DC |
| Input Voltage | 16-36V | |
Environment | Operation Temp. | With air flow -10 ~ 60° C |
| Storage Temp. | -20 ~ 70° C | |
| Relative Humidity | 95% @ 40° C (non-condensing) | |
| Anti-vibration | With SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis | |
| Anti-shock | With SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration | |
| Mechanical | Mounting | Desktop / wall mounting |
| Dimension (mm) | 220 mm x 227.5 mm x 84 mm | |
| Construction | Aluminum housing | |
| OS | Windows 10/11 64bit , Linux 64bit | |
Founded in 2016, Vstrong Technology Co.,Ltd is headquartered in Shenzhen, China. Our team of experienced and trusted experts is dedicated to continuously providing industrial computer systems including Industrial Motherboard, Industrial Panel PC, Fanless Box PC, Industrial Monitor, Rugged Tablets, etc. Meanwhile we provide flexible customization tailored to various applications.
From industrial automation, warehouse and logistics, smart traffic, construction, manufacturing, retail and other industries that require durability and ease of use, you will find our products and services working hard for clients who expect only the best. We always listen to customer needs and act on them.You can reply on Vstrong Technology to deliver and work with.
Main Advantages:
Robust and Reliable Products: Our industrial PCs are built to last in demanding environments. You can rely on them for uninterrupted performance, ensuring your operations run smoothly without costly downtime.
Flexible Customization: Tailored solutions to fit your exact needs. With flexible customization options, you get the precise hardware and features required for your unique applications, maximizing efficiency.
Cost-Effective Solutions: We offer budget-friendly solutions without compromising on quality. Our cost-effective industrial PCs deliver exceptional value, helping you save on upfront costs and long-term operational expenses.
Quality Assurance: Our commitment to quality is unwavering. We adhere to stringent quality control processes to guarantee that every industrial PC we provide meets the highest industry standards, ensuring your investment is worthwhile.
Longevity and Lifecycle Support: We understand the importance of long-term reliability. Our industrial PCs come with extended product lifecycles and comprehensive support, safeguarding your investment and minimizing disruptions over the years.
